BRAND: MAZDA
|
MODEL: WSXR3715
|
REF: wsxr3715
|
CAT: External Wall Light
ACTIVE
PHOTOMETRIC ANALYSIS
BEAM PATTERN
CCT: 4000K
INT: NOMINAL
External Wall Light
ROCK
The wall lamp rock led by the Mazda LED manufacturer light-point is from aluminium which is affixed to the wall. It is
available in a choice of classical colours. Its LED light illuminates the wall upwards and downwards. The diffusers which
are adjustable and make it possible to vary the upwards and downwards directed diffusers. The light beams can be very
concentrated, broad or very broad.
WATT
CCT
Voltage
Body Color
Control
Dimension
Emergency Backup
Technical Specifications
Code
WSXR3715
WATT
1X6W / 2X6W / 1X8W / 2X8W
CCT
3000 / 4000 / 5000 / 6000 / 2700 / 6500
Voltage
240V
Body Color
BLACK, DARK GREY, SILVER, WHITE
Control
ON - OFF / DALI DIMMABLE DRIVER / PHASE CUT DIMMABLE / 0/1-10 V DIMMABLE DRIVER
Emergency Backup
NON EMERGENCY
Beam Angel
15°, 24°, 36°
Dimension
A100 X B160 X C56 MM / A95 X B165 X C67 MM
Material
DIE CAST ALUMINUM
IP
IK08
