BRAND: MAZDA
|
MODEL: DXR1792
|
REF: dxr1792
|
CAT: Downlight
ACTIVE
PHOTOMETRIC ANALYSIS
BEAM PATTERN
CCT: 4000K
INT: NOMINAL
PANELO SQ
Downlight

PANELO SQ

MODEL: DXR1792
SKU: dxr1792
BRAND: MAZDA

Panelo SQ is a square shaped down light recongnised as one of the most trusted and highly desirable consumer fitting, we
manufactured it to the highest standards. This superior design skillfully prevent the human eyes contact with the light
sources directly, makes the light more soft. Meanwhile the light efficiency reach to 120lm/w with perfect accent lighting
performance. That makes it become the priority selected product for commercial lighting. Great cooling fins heat sink
design increases the interface between heat sink and air, which makes the heat dissipating performance outstanding and
extend the service life of the downlight. Suitable for commercial and residential applications like office, supermarket, shop,
school, hotel, restaurant, workshop, warehouse, home etc

WATT
CCT
Voltage
Body Color
Control
Dimension
lumen
Emergency Backup
GENERATED PRODUCT CODE
SELECT OPTIONS ABOVE
GENERATE DATASHEET

Technical Specifications

Code
DXR1792
WATT
08W / 12W / 15W / 18W / 20W / 25W / 30W / 40W
CCT
3000 / 4000 / 5000 / 6000 / 2700 / 6500
Voltage
240VAC
Body Color
WHITE
Control
0/1-10 V DIMMABLE DRIVER / PHASE CUT DIMMABLE / ON - OFF / DALI DIMMABLE DRIVER
Emergency Backup
NON EMERGENCY
Beam Angel
45
Dimension
A100 X B100 X C37MM / A135 X B135 X C37MM / A165 X B165 X C37MM / A215 X B215 X C37MM
Material
DIE CAST ALUMINUM
IP
IP54
lumen
960LM / 1440LM / 1800LM / 2160LM / 2400LM / 3000LM / 3600LM / 4800LM
