BRAND: MAZDA
|
MODEL: DXR1790
|
REF: dxr1790
|
CAT: Downlight
ACTIVE
PHOTOMETRIC ANALYSIS
BEAM PATTERN
CCT: 4000K
INT: NOMINAL
Downlight
RINGO
Ringo LED Down Light is recessed aluminium downlight available in white. This downlight design has been finished with a
special paint treatment to ensure an extra-long lifespan and making it suitable for use under eaves and in water areas such
as showers. It features semi anti-glare with a deep positioning, and can be installed under insulation using an ICD driver,
great thermal management, IP65 waterproof with high protection level, which offers a wider application area
WATT
CCT
Voltage
Body Color
Control
Dimension
lumen
Emergency Backup
Technical Specifications
Code
DXR1790
WATT
10W / 15W / 20W / 30W / 40W
CCT
3000 / 4000 / 5000 / 6000 / 2700 / 6500
Voltage
240VAC
Body Color
WHITE
Control
0/1-10 V DIMMABLE DRIVER / PHASE CUT DIMMABLE / ON - OFF / DALI DIMMABLE DRIVER
Emergency Backup
NON EMERGENCY
Beam Angel
24
Dimension
A115 X B78 X C100MM / A135 X B78 X C120MM / A170 X B80 X C150MM / A195 X B95 X C170MM / A220 X B105 X C200MM
Material
DIE CAST ALUMINUM
IP
IP65
lumen
1200LM / 1800LM / 2400LM / 3600LM / 4800LM
